DON'T LET CORROSION EAT INTO YOUR INVESTMENT DEMAND "RELIANCE" MIL SPEC ANODES.

Galvanic series of various metals exposed to sea water:

Magnesium                                                                   Lead-Tin Solders

Zinc                                                                              Silver

Silicon Bronze                                                               Nickel (Active)

M-Bronze                                                                     18-8 Stainless Steel, Type 304 (Passive)

Wrought Iron                                                                13" Chromium Stainless Steel, Type 410 (Passive)

Titanium                                                                        Copper

Tin                                                                                Aluminum 6053

Naval Brass                                                                  G-Bronze

18-8 Stainless Steel, Type 304 (Active)                          Silver Solder

18-12-3 Stainless Steel, Type 316 (Passive)                   67 Ni-33 Cu Alloy (Monel)

Yellow Brass                                                                Lead

Galvanized Steel                                                          Gold

Mild Steel                                                                    CATHODIC (Passive, Most Noble)

Cadmium

Mild Steel

Cast Iron




 The United States Naval Command joined forces with the International Zinc Institute in the early 1950's to research and improve the performance of common zinc as a sacrificial anode.  They discovered the elimination of iron contamination to less than fourteen parts in ten thousand, coupled with the addition of controlled amounts of aluminum and cadmium, enhanced the anodes performance significantly.  The research yielded the US Naval Mil-Spec MIL-A-18001 the highest standard of anodes quality.

 Why use "Reliance" Anodes?

Reliance anodes are made from a high purity zinc with added catalysts to produce an "activated alloy", ensuring the anodes give one hundred percent of themselves to protect your boat from corrosion action.  In order for an anode to work properly it must be free of unwanted impurities.


Understanding "Mil-Spec: MIL-A-18001"
